Monitoring the uptime of an application with Python, Nuxt.js and QuestDB
Highly available services that serve millions of requests rely on the visibility of the system status for customers and internal teams. This tutorial shows how a lightweight and performant time-series database coupled with queued status checks and a simple UI are key ingredients for robust application monitoring.
Why build a status page for an application?
Even if we design the most reliable systems, incidents will occur for hard-to-predict reasons. It’s critical to provide as much information as possible to users, customers, and service teams. The most convenient way to display this is through a status page.
Although the page’s responsibility is to provide information, it can reduce the support team’s load and eliminate duplicate support tickets. Status pages are a crucial part of incident management, and usually, other teams enjoy benefits like client and service owners when they need to refer to SLAs. In this tutorial, I’ll show you how to build a simple yet powerful status page that scores well on performance and design.
What we will build
Overview
As mentioned above, we will build a simple status page made of two parts: the backend monitors our service, and a frontend shows our services’ status on an hourly scale.
You will need some experience in Python, JavaScript, and basic SQL knowledge. To build our service, we will use FastAPI, an ultra-fast Python web framework, Celery for scheduling monitoring tasks, QuestDB, the fastest open-source time-series database, to store monitoring results, and NuxtJs to display them.
There’s a lot to learn, so let’s jump right in!
Prerequisites
You will need to have the following installed on your machine:
Python 3.8
NodeJS 14+
Docker
Docker Compose
Setting up the environment
Create a new project
First things first, we create a directory, called status-page
, this is our project root. We also need to create another directory called app
which will contain the backend code. After following these steps, you should have a project structure like this.
status-page (project root)
└── app (backend service directory)
Installing QuestDB & Redis
Now, we will install QuestDB and Redis. QuestDB is used to store the HTTP status and the service state of our application over time, and Redis is used as a message broker between the backend application and the workers who will do the scheduled monitoring.
To install these services, we will use Docker and Docker Compose. We are going to create a docker-compose.yml
file within the project root with the following content:
version: '3'
volumes:
questdb_data: {}
services:
redis:
image: 'redis:latest'
ports:
- '6379:6379'
questdb:
image: 'questdb/questdb:latest'
volumes:
# Map QuestDB's data directory to the host
- 'questdb_data:/root/.questdb/db'
ports:
- '9000:9000'
- '8812:8812'
Voila! When we run docker-compose up
, QuestDB and Redis start, and we can access QuestDB's interactive console on http://127.0.0.1:9000.
Install backend dependencies
Now, we have the project structure, and we can run the required services, so we need to set up our backend service to collect data about the website or service we would like to monitor. We will use poetry to manage Python dependencies during this tutorial, so let’s start by installing that.
$ pip install poetry
To define the project requirements, create a pyproject.toml
file with the following content:
[tool.poetry]
name = "status-page"
version = "0.1.0"
description = "QuestDB tutorial for creating a simple status page."
authors = ["Your name <your.email@example.com>"]
license = "MIT"
[tool.poetry.dependencies]
python = "3.8"
[build-system]
requires = ["poetry-core>=1.0.0"]
build-backend = "poetry.core.masonry.api"
Install the project dependencies by executing the following:
$ poetry add python fastapi pydantic uvicorn requests \
psycopg2-binary "databases[postgresql]" "celery[redis]"
As you may assume by checking the requirements, we will use QuestDB’s Postgres interface to connect. When poetry
finishes its job, it will add the dependencies to pyproject.toml
and we can now start to implement the backend service.
Create a simple API
The time has come, let’s create the backend service, but step-by-step. Within the app
directory, create an __init__.py
and main.py
. The first one is responsible for making the app
directory to a package, while the latter will define the APIs our service exposes. Open main.py
for edit and add the following:
# main.py
from fastapi import FastAPI
app = FastAPI(
title="Status Page",
description="This service gives back the status of the configured URL.",
version="0.1.0",
)
Congratulations! You just created the backend service. You can go and try it out by executing:
$ poetry run uvicorn app.main:app --host 127.0.0.1 --port 8000 --reload
INFO: Uvicorn running on http://127.0.0.1:8000
...
INFO: Application startup complete.
Although the service does nothing yet, it works and listens for any code change. Add a new endpoint and watch it reload:
# main.py
# ...
@app.get(path="/signals", tags=["Monitoring"])
async def get_signals():
return {}
We have now created an API endpoint that will serve the system status data of the monitored URL. If you open http://127.0.0.1:8000/redoc, you can see the generated documentation for the endpoint, or you can check it working at http://127.0.0.1:8000/signals, though it won't return any data yet.
It is time to have fun, we are going to integrate QuestDB with our shiny new backend service.
Integrate QuestDB with FastAPI
Integrating QuestDB with FastAPI is easier than you think. Thanks to QuestDB’s Postgres compatibility, you can use any standard or popular third-party libraries of any programming language which implements Postgres wire protocol.
Set up the table
The very first step is to create the table in QuestDB. As said before, our approach is simple, so that the table is simple, too. QuestDB is running from our docker compose script so, we open the interactive console at http://127.0.0.1:9000 and create a new table by running the following query:
CREATE TABLE
signals(url STRING, http_status INT, received TIMESTAMP, available BOOLEAN)
timestamp(received);
The query executes, and after refreshing the table list on the left, you can see the table we created.
Connect QuestDB and FastAPI
As we have the table in the database, it is time to connect to QuestDB and query some data to return through the API. To connect, we will use the Postgres interface of QuestDB and SQLAlchemy to connect to it.
To be able to reuse the engine later on, create a new file in the app
package which is responsible for defining how to connect and name it db.py
:
# db.py
from sqlalchemy import create_engine
engine = create_engine(
"postgresql://admin:quest@127.0.0.1:8812/qdb", # Use a the default credentials
pool_size=5, # Set pool size greater than 1 to not block async requests
pool_pre_ping=True # Set pre-ping to ensure a connection is opened when sending a query
)
To set up a schema that represents the table in the database, create a models.py
containing the schema definition:
# models.py
from datetime import datetime
from pydantic import BaseModel, Schema
class Signal(BaseModel):
url: str = Schema(..., description="The monitored URL")
http_status: int = Schema(..., description="HTTP status code returned by upstream")
available: bool = Schema(..., description="Represents the service availability")
received: datetime = Schema(..., description="Timestamp when the signal received")
Let’s stop here for a moment and talk through what we did in the last steps:
set up the API which will serve the requests coming from the frontend
created a table in QuestDB for our status records and provided connection credentials for Postgres wire
implemented the schema which is used to serialize the results returned by the database
The next step is to initiate a connection and return the results from the database. First, import the engine
and Signal
schema and then extend the function which serves the /signals
endpoint:
# main.py
# Other imports ...
from app.db import engine
from app.models import Signal
from typing import List
from pydantic import BaseModel
class SignalResponse(BaseModel):
url: str
records: List[Signal]
After adding the defaultdict
import, the implementation of the /signals
endpoint should look like this:
# main.py
# Other imports ...
from collections import defaultdict
# ...
@app.get(path="/signals", response_model=List[SignalResponse], tags=["Monitoring"])
async def get_signals(limit: int = 60):
# A simple query to return every record belongs to the website we will monitor
query = f"""
SELECT * FROM signals
WHERE url = 'https://questdb.io' ORDER BY received DESC LIMIT {limit};
"""
signals = defaultdict(list)
with engine.connect() as conn: # connect to the database
for result in conn.execute(query): # execute the SELECT query
signal = Signal(**dict(result)) # parse the results results returned by QuestDB
signals[signal.url].append(signal) # add every result per URL
# Return the response which is validated against the `response_model` schema
return [
SignalResponse(url=url, records=list(reversed(records)))
for url, records in signals.items()
]
Let’s recap on our code above, starting from the top:
we added
defaultdict
import (we'll explain that later)extended the function decorator to use
response_model=List[SignalResponse]
, the response model we defined alreadychanged the function signature to include a
limit
parameter and set its default value to60
since we will monitor HTTP status every minuteselect the records from the database and prepare a dictionary for the parsed
Signal
s.
You may ask why to group the returned records per URL. Although we will monitor only one URL for the sake of simplicity, I challenge you to change the implementation later and explore QuestDB to handle the monitoring of multiple URLs.
In the following lines, we are connecting to the database, executing the query, and populates the dictionary, which we will use in the last four lines to construct the SignalResponse
. Our version of main.py
at this point looks like the following:
# main.py
from collections import defaultdict
from typing import List
from fastapi import FastAPI
from pydantic import BaseModel
from app.db import engine
from app.models import Signal
# Add a response model to indicate the structure of the signals API response.
class SignalResponse(BaseModel):
url: str
records: List[Signal]
app = FastAPI(
title="Status Page",
description="This service gives back the status of the configured URL.",
version="0.1.0",
)
@app.get(path="/signals", response_model=List[SignalResponse], tags=["Monitoring"])
async def get_signals(limit: int = 60):
# A simple query to return every record belongs to the website we will monitor
query = f"""
SELECT * FROM signals
WHERE url = 'https://questdb.io' ORDER BY received DESC LIMIT {limit};
"""
signals = defaultdict(list)
with engine.connect() as conn: # connect to the database
for result in conn.execute(query): # execute the SELECT query
signal = Signal(**dict(result)) # parse the results results returned by QuestDB
signals[signal.url].append(signal) # add every result per URL
# Return the response which is validated against the `response_model` schema
return [
SignalResponse(url=url, records=list(reversed(records)))
for url, records in signals.items()
]
Schedule monitoring tasks
For scheduling the monitoring task, we will use Celery Beat, the built-in periodic task scheduler implementation of Celery.
Scheduling with Celery
Before we schedule any task, we need to configure Celery. In the app
package, create a new celery.py
which will contain the Celery and beat schedule configuration. Import Celery
for creating tasks, and crontab
for constructing Unix-like crontabs for our tasks. The task is the dotted path representation of the function which is executed by Celery (app.tasks.monitor
) and sent to queues handled by Redis.
The only thing left is to configure the beat schedule, which is a simple dictionary. We give a name for the schedule, define the dotted path pointing to the task (function), and specify the schedule itself:
# celery.py
from celery import Celery
from celery.schedules import crontab
MONITORING_TASK = "app.tasks.monitor"
celery_app = Celery("tasks", broker="redis://localhost:6379/0")
# Set a queue for task routes
celery_app.conf.task_routes = {
MONITORING_TASK: "main-queue"
}
# Schedule the monitoring task
celery_app.conf.beat_schedule = {
"monitor": { # Name of the schedule
"task": MONITORING_TASK, # Register the monitoring task
"schedule": crontab(
minute=f"*/1" # Run the task every minute
),
}
}
Create a monitoring task
And the last part: creating the monitoring task. In the previous section, we talked about the “monitoring task” multiple times, but we didn’t see the concrete implementation.
In this final backend related section, you will implement the task which will check the availability of the desired website or service and saves the results as records in QuestDB. The monitoring task is a simple HTTP HEAD
request and saving the response to the database. We see the implementation in pieces of the tasks.py
referenced in celery as the dotted path before.
First, we start with imports:
# tasks.py
from datetime import datetime
import requests
from app.celery import celery_app
from app.db import engine
from app.models import Signal
# ...
We import celery_app
which represents the Celery application, an engine
to save the results in the database, and finally Signal
to construct the record we will save. As the necessary imports are in place, we can define the monitor
task.
# tasks.py
# ...
@celery_app.task # register the function as a Celery task
def monitor():
try:
response = requests.head("https://questdb.io")
except Exception as exc: # handle any exception which may occur due to connection errors
query = f"""
INSERT INTO signals(received,url,http_status,available)
VALUES(systimestamp(), 'https://questdb.io', -1, False);
"""
# Open a connection and execute the query
with engine.connect() as conn:
conn.execute(query)
# Re-raise the exception to not hide issues
raise exc
# ...
As you can see, we send a request to the desired website and store the response for later use. In case the website is down and unreachable, an exception will be raised by requests or any underlying packages. As we need to log that the request does not finish, we catch the exception, save a record in the database, and re-raise the exception to not hide anything. Next, we construct a signal to save.
# ...
@celery_app.task
def monitor():
# ...
signal = Signal(
url="https://questdb.io",
http_status=response.status_code,
received=datetime.now(),
available=response.status_code >= 200 and response.status_code < 400,
)
# ...
We don’t do anything special here, though the following step is more interesting: inserting the result in the database. Finally, we prepare and execute the query based on the signal
.
# ...
@celery_app.task
def monitor():
# ...
query = f"""
INSERT INTO signals(received,url,http_status,available)
VALUES(systimestamp(), '{signal.url}', {signal.http_status}, {signal.available});
"""
with engine.connect() as conn:
conn.execute(query)
Congratulations! You just arrived at the last part of the backend service implementation. We did many things and built a service that can periodically check the website’s status, save it in the database, and expose the results through an API.
The very last thing we need to address is to allow connections initiated by the frontend later on. As it will run on localhost:3000 and we don’t use domain names, the port is different hence all requests will be rejected with errors related to Cross-Origin Resource Sharing.
To address this issue, add the following middleware to the application which will allow us to connect at http://localhost:3000:
# main.py
# Other imports ...
from fastapi.middleware.cors import CORSMiddleware
# app = FastAPI ...
app.add_middleware(
CORSMiddleware,
allow_origins=["http://localhost:3000"],
allow_credentials=True,
allow_methods=["*"],
allow_headers=["*"],
)
# ...
Implement the frontend
Setting up frontend
To build the frontend, we will use Nuxt.js. We will use yarn
to set up the starter project by running yarn
and selecting the answers detailed below.
$ yarn create nuxt-app frontend
[...]
? Project name: frontend
? Programming language: JavaScript
? Package manager: Yarn
? UI framework: Tailwind CSS
? Nuxt.js modules: Axios
? Linting tools: (Press <space> to select, <a> to toggle all, <i> to invert selection)
? Testing framework: None
? Rendering mode: Single Page App
? Deployment target: Static (Static/JAMStack hosting)
? Development tools: (Press <space> to select, <a> to toggle all, <i> to invert selection)
? What is your GitHub username? gabor-boros
? Version control system: Git
The project root now looks like this:
status-page
├── app/
├── frontend/
├── docker-compose.yml
├── poetry.lock
└── pyproject.toml
Cleaning up generated project
Since we don’t need any styling delivered by the project generation, we need to get rid of them. Open frontend/layouts/default.vue
and replace its content with:
<!-- frontend/layouts/default.vue -->
<template>
<div>
<Nuxt />
</div>
</template>
Now, we will change frontend/pages/index.vue
and call the backend service. Let's begin with <scripts>
.
<!-- frontend/pages/index.vue -->
<!-- template ... -->
<script>
const LIMIT = 60;
async function fetchSignals($axios, limit) {
const signals = await $axios.$get(`http://localhost:8000/signals?limit=${limit}`)
return signals
}
export default {
data() {
return {
signals: []
}
},
// Handle initial call
async asyncData({ $axios }) {
const signals = await fetchSignals($axios, LIMIT)
return { signals }
},
methods: {
// Calculate uptime based on the signals belongs to a URL
uptime: (records) => {
let availableRecords = records.filter(record => record.available).length;
return ((availableRecords / records.length) * 100).toFixed(2)
}
},
// Set up periodic calls when the component is mounted
mounted() {
let that = this
const axios = this.$axios;
setInterval(() => {
Promise.resolve(fetchSignals(axios, LIMIT)).then((signals) => {
that.signals = signals
});
}, 1000 * LIMIT);
}
}
</script>
At the first sight, it might look a lot, but if we check the most important parts in pieces everything will be crystal clear.
We define fetchSignals
to reduce code duplication later on. Then, we set up initial signals
data, where we will store the periodically fetched responses returned by the backed. After that, as part of asyncData
, we initiate an async call towards the backend to get the initial signals to show.
The last part is to define a periodic call to the backend when the component is mounted
. Right, we have the logic which will call backend and keep the data up to date. Now we have to display the results.
<!-- frontend/pages/index.vue -->
<template>
<div class="p-8 h-screen text-center">
<h1 class="text-2xl font-light">QuestDB website status</h1>
<h2 class="text-lg font-thin">service uptime in the past 60 minutes</h2>
<div class="h-8 mt-12 flex justify-center" v-if="signals.length > 0">
<!-- Iterate over the signals belongs to records -->
<div class="w-1/4" v-for="(signal, s) in signals" :key="s">
<div class="flex mb-1 text-sm">
<p class="flex-1 text-left font-normal">{{ signal.url }}</p>
<p class="flex-1 text-right font-thin">{{ uptime(signal.records) }}% uptime</p>
</div>
<div class="grid grid-flow-col auto-cols-max gap-x-1">
<!-- Draw a green or yellow bar depending on service availability -->
<div
v-for="(signal, r) in signal.records"
:key="r"
:class="`w-1 bg-${signal.available ? 'green' : 'yellow'}-700`"
> </div>
</div>
</div>
</div>
<!-- In case we have no records yet, show an informative message -->
<div v-else>
<p>No signals found</p>
</div>
</div>
</template>
<!-- scripts ... -->
Run the project
We reached the end of the tutorial. We have both the backend and the frontend. It is time to try everything out. Run the following commands in different shells from the project root:
# Shell 1 - Start the application
$ docker-compose up -d
$ poetry run uvicorn app.main:app --host 127.0.0.1 --port 8000 --reload
# Shell 2 - Start the worker process
$ poetry run celery --app=app.tasks worker --beat -l info -Q main-queue -c 1
# Shell 3 - Start the frontend
$ cd frontend
$ yarn dev
Navigate to http://localhost:3000 to see the backend reporting the status of the monitored URL. The first task to check the system status is executed when the scheduler and worker starts and the status of the website over time can be seen after a few minutes on the page or when you check back at a later stage:
Summary
We’ve successfully built a pretty status page that can be publicly-visible to users or used for internal teams to monitor an application’s uptime. We’ve learned how to queue and schedule tasks and store the responses in a time-series database and make use of low-latency queries. Engineers can modify this demo to monitor a website’s HTTP response code or multiple endpoints or services for a robust overview of an entire system’s status.
The containerized source code is available at https://github.com/gabor-boros/questdb-statuspage.
